Post-Departure Revenue Reporting
Network Planning & Scheduling › Revenue Management · 17 L4 steps · 5 phases · 6 decision gates · Updated 2026-03-18 19:10
📊
Process Flow Diagram (BPMN)
📋
L4 Process Steps
| Step | Step Name | Role / Swim Lane | System | Input | Output | KPI | Dec? | Exc? |
|---|---|---|---|---|---|---|---|---|
Phase 1 1.1 |
Trigger post-departure PSS revenue extract | Revenue Reporting Analyst | Amadeus Altéa PSS | Flight departure confirmation signal from Altéa DCS | Raw booking & ticketing record extract per flight | Extract available within 30 min of block-in; ≥99.5% flight coverage | N | N |
| 1.2 | Pull ancillary revenue feeds from ancillary platform | Revenue Reporting Analyst | Amadeus Altéa Ancillary (Ancillary Services Manager) | Completed flight leg; ancillary transaction logs | Per-flight ancillary revenue breakdown (bags, seat upgrades, extras) | Ancillary revenue captured per passenger ≥ airline target (e.g. USD 28/pax industry benchmark) | N | Y |
| 1.3 | Validate booking-to-flown passenger completeness | Revenue Reporting Analyst | Amadeus Altéa PSS | DCS final manifest; booking record extract | Reconciled flown passenger count with no-show & offload flags | Booking-to-manifest match rate ≥99.8% before proceeding | Y | Y |
Phase 2 2.1 |
Reconcile ticketed revenue vs. flown revenue | Revenue Accounting Analyst | SAP S/4HANA Finance (FI/CO) | Altéa ticketing extract; flown passenger manifest | Flight-level ticketed vs. flown revenue variance report | Revenue variance tolerance ≤1% of flight revenue before exception flag | Y | Y |
| 2.2 | Match BSP & interline settlement amounts | Revenue Accounting Analyst | IATA BSPlink | BSP billing files; interline prorate agreements | Settled interline revenue allocation per flight segment | BSP settlement matched within 48 hours of departure; dispute rate <0.5% | N | Y |
| 2.3 | Validate upgrade & no-show revenue capture | Revenue Accounting Analyst | Amadeus Altéa PSS | No-show records; upgrade transaction log from DCS | Confirmed no-show penalty revenue and upgrade delta postings | No-show revenue leakage <0.2% of total flight revenue | Y | Y |
Phase 3 3.1 |
Aggregate O&D revenue by fare class & cabin | Revenue Management Analyst | Amadeus Revenue Management (NRM) | Reconciled flight revenue records; booking class mapping | O&D revenue matrix by fare class, cabin, and market pair | O&D attribution completeness ≥98% of total flight revenue | N | N |
| 3.2 | Calculate RASM, PRASM, and load factor vs. forecast | Revenue Management Analyst | Amadeus Revenue Management (NRM) | O&D revenue matrix; capacity data from Amadeus SkyWORKS | Flight-level RASM, PRASM, load factor actuals vs. forecast delta | RASM actuals within ±3% of pre-departure NRM forecast; load factor ≥83% | N | N |
| 3.3 | Identify revenue spoilage and dilution events | Revenue Management Analyst | Amadeus Revenue Management (NRM) | RASM/PRASM variance report; fare class booking curve | Spoilage flag (unsold high-yield seats) or dilution flag (over-discounted load) | Spoilage rate ≤4% of available seats on constrained routes; dilution rate ≤2% | Y | Y |
Phase 4 4.1 |
Generate flight-level post-departure P&L report | Revenue Reporting Manager | SAP S/4HANA Finance (FI/CO) | Reconciled revenue; ancillary revenue; prorate settlements | Flight-level revenue P&L report with actuals vs. plan variance | Report generation within 4 hours of block-in for priority routes | N | N |
| 4.2 | Publish variance dashboard for RM and Finance | Revenue Reporting Manager | Tableau | Flight P&L report; RASM/PRASM variance data | Interactive revenue variance dashboard published to BI portal | Dashboard refresh latency ≤1 hour from report generation; stakeholder access rate ≥90% | N | N |
| 4.3 | Route significant variances to Revenue Director | Revenue Reporting Manager | SAP S/4HANA Finance (FI/CO) | Variance dashboard; threshold breach flags | Escalation notification with variance summary and root-cause annotation | Escalation triggered within 2 hours for variances ≥5% of planned flight revenue | Y | N |
| 4.4 | Distribute approved reports to RM and Finance teams | Revenue Director | AWS S3 | Approved flight-level revenue reports | Published report package to S3 data lake for downstream consumption | Distribution to all stakeholders within 6 hours of block-in for same-day flights | N | N |
Phase 5 5.1 |
Feed actuals into NRM for forecast comparison | Revenue Management Analyst | Amadeus Revenue Management (NRM) | Finalised flight revenue actuals from S3 data lake | Actuals posted to NRM historical performance database | Actuals feed completed within 24 hours of departure; data completeness ≥99% | N | Y |
| 5.2 | Assess forecast model error vs. recalibration threshold | Revenue Management Analyst | Amadeus Revenue Management (NRM) | Actuals vs. NRM forecast delta; rolling MAPE statistics | Recalibration decision flag: proceed or trigger model update | MAPE ≤8% on 30-day rolling basis; trigger recalibration if MAPE >10% for 5 consecutive days | Y | Y |
| 5.3 | Trigger NRM demand model recalibration job | RM Systems Administrator | Amadeus Revenue Management (NRM) | Recalibration trigger flag; accumulated actuals dataset | Updated NRM demand model parameters; recalibration completion log | Recalibration job completes within 6-hour maintenance window; model improvement verified by ≥1% MAPE reduction | N | Y |
| 5.4 | Archive finalised flight revenue record to data lake | Revenue Reporting Analyst | AWS S3 | Validated & reconciled flight revenue package | Immutable flight revenue archive record in S3 with audit trail | 100% of departed flights archived within 24 hours; retention compliance per IATA Resolution 787 (7-year minimum) | N | N |
📋
